LC-WNS3200

3,600 ANSI lumens bright with 80% uniformity and a 5000:1 contrast ratio.

Native WXGA resolution. Compatible with inputs up-to UXGA and WUXGA.

Supports analog and digital video input in all color standards up-to 1080p.

HDMI Digital connectivity with HDCP compliance.

Convenient mid-range (1.2:1) manual zoom and focus lens.

Fixed image offset. Automatic vertical digital keystone correction.

Accepts composite, component, and S-Video in all major standards.

Displays both 4:3 and 16:9 aspect ratios. Supports most HDTV resolutions.

Built-in 7 Watt sound system. Closed Caption decoding (NTSC).

Wired network control. Digital zoom: 50% to 400%.

Side-accessed air filter and top-accessed lamp for ease of maintenance.

Color board modes. Custom warm-up screen.

Auto input selection. Built-in Test Patterns.

Security bar. Kensington® MicroSaver® security slot. PIN lock.

Ανήκει στη σειρά: LCD Technology

Τεχνικά Xαρακτηριστικά
Φωτογραφίες
Προϊόντα ίδιας σειράς

Display Technology 3 LCD

Brightness (ANSI) up-to 3,600 ANSI Lumens

Native Resolution WXGA (1280×800)

Max. Computer Input UXGA/WSXGA+

Max. Video Input 1080p

Contrast Ratio up-to 5000:1

Panel Size 0.59 in (15 mm)

Lens Type (Throw:Width)

Attached – Manual Zoom and Focus (1.45 ~ 1.74:1)

Fixed Image Offset, Ratio (Top/Bottom) 13:1

Keystone Correction 30° Up or Down

Image Signal Inputs

Computer 1 – Dsub15 x 1, Computer 2 – Dsub15 x 1 (Switchable Monitor Output), HDMI (w/HDCP) x 1, S-Video x 1, Component Video RCA x 3, Composite Video RCA x 1

Audio Inputs

Computer Audio – Mini-Stereo x 1, Video Audio – RCA x 2 (L/R)

Outputs

Computer Monitor (Computer 2) – Dsub15 x 1, Audio Output Variable, Stereo: MiniStereo x 1

Sound System 7 Watt; 1.4 in (3.7 cm) x 1 (Mono) speaker

Network Control Wired LAN for projector control

Fan Noise as low as 32 dBA

Maximum Pitch Up-to 30° Up or Down

Weight 6.7 lb. (3.05 kg)
