Performance
Frequency response in-room 20Hz – >20kHz ±3dB (for inputs at 44.1kHz or 48kHz)
‘3 1/2-way' crossover system
Linear-phase mid–top crossover; 6th-order Linkwitz-Riley bass–mid crossover
Output >118dB spl @ 1m on music material
Noise less than 15dB spl
Overall distortion typically <0.02% at any frequency or level

Inputs
SpeakerLink balanced digital (2ch, RJ45)
S/PDIF unbalanced digital (2ch, phono)
32kHz–96kHz sampling rates

Audio Processing
FIFO memory buffer input for the lowest possible jitter from almost any source
Four 24-bit D/A converters
3x150W amps on bass (1 amp per driver pair)
2x150W amps on midrange and tweeter
All upsampling and processing is performed a 150MHz digital signal processor (DSP)

Construction
Two separate enclosures: mid/top and bass.
Horizontally opposed and profiled bass system introduces minimal vibration to the mid/top enclosure
6 x 200mm long-throw bass drivers
1 x 160mm polypropylene (TPX) mid driver in separate enclosure
1 x 25mm dome tweeter, silver wire, short horn-loaded with protective grille
Black or silver gloss piano-lacquer with glass front bass cabinet
Also available in other colours to special order

Dimensions
1350mm (53.2in) H, 400 (15.7) W, 528 (20.8) D – weight 105kg (231lb) each

Control
Rear-panel controls for Power On/Off. Full control via MSR+ and RS232
SpeakerLink carries Comms, serial and balanced digital audio via RJ45/CAT 5

Front display
Multi-character display with system lights

Power
20W standby, 920W max
