Type: Non Magnetic Core Moving Coil

Frequency Response: 15 to 50,000 Hz

Channel Separation: 30 dB (1 kHz)

Channel Balance: 0.5 dB (1 kHz)

Coil Impedance: 11.5 W (1 kHz)

DC Resistance: 11.5 W

Vertical Tracking Angle: 23 degrees

Recommended Load Impedance: Min 100 W

Coil Inductance: 7 mH (1 kHz)

Static Compliance: 35 x 10 – 6 cm / dyne

Dynamic Compliance: 10 x 10 – 6 cm / dyne (100 Hz)

Output Voltage: 0.12 mV (at 1 kHz, 5 cm/sec)

Stylus Shape: Line Contact Stylus

Cantilever: 0.26 mm Ø solid boron

Stylus Construction: Nude square shank

Mount: 1/2” centers

Dimensions: 17.3 (H) x 17.0 (W) x 25.6 (L) mm

Weight: 10 g

Accessories: Non magnetic screw driver; 1 brush; 2 washers; 2 x 12 mm mounting screws; 2 x 18 mm mounting screws; 1 plastic protector; 1 set of PCOCC Lead Wires (AT6106)
