LIGHT ENGINE
DLP® Type 3 Chip DMDs 0,95” 1080p DC4
Resolution 1920x1080 pixels
Lens High quality, high resolution improved optics for higher contrast and better black level with motorized zoom and focus adj.
Lamp power consumption 260W dimmable to 230W
Lamp life expectancy  2500 hours typical in standard power mode; 3000 hours in ECO mode
Brightness up to 2600 Ansi Lumens (adjustable)
Contrast ratio (Full ON / OFF) > 10.000:1
Special Features: Puremotion 3D technology, Puremotion 2D for fast action materials, Puremovie 2D

INSTALLATION
Throw ratio standard lens 1.82-2.48:1 (type T2)
Throw ratio optional lenses 1.37-1.66:1 (typ. T1); 2.6-3.9:1 (typ. T3)
Optical shift manual up half picture (+50%) and Digital keystone adjustment
Picture size (typical - inches diagonal) 50-250
Aspect ratio 4:3, 16:9 Anamorphic, LetterBox, Panoramic, Pixel to Pixel + 3 custom-user adjustments

ELECTRONICS
Horizontal & vertical scan freq. 15-80kHz/24-120Hz
SDTV PAL (B,G,H,I,M,N,60); SECAM; NTSC autom. selected
HDTV 480p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p
PC graphic standard VGA, SVGA, XGA, SXGA, UXGA, WUXGA 10 bit Full Channel Signal Board Video Processing

INPUTS/OUTPUTS
Digital
2 x HDMI-HDCP vers. 1.4a with Instaport
Analog
1 x Composite Video (RCA)
1 x Graphic RGBVH (VGA-UXGA) (D-sub 15 pin)
1 x Component - Analog YPbPr/RGBs/RGBHV (RCA)
Control
1 x 3D Sync Out
1 x RS232 (D-sub 9 pin)
1 x USB
Miscellaneous

GENERAL SPECIFICATIONS
Software control upgradable via RS232, serial interface or USB
Mains voltage range 100-240 +/-10% (48/62 Hz)
Projector Weight 11 Kg. or 24.3 lbs

ACCESSORIES
Supplied
Premium Visus Active Glasses (4 pcs.)
IR Emitter
Installation and User Manual
AC power cords (2m - 6.6 ft)
Backlit remote control and batteries
Live Colors Calibration software
Optional
Projector ceiling bracket (cod. LUMISBRKT)
Anamorphic lens systems (fixed or motorized)
Additional active glasses

CABINET COLORS
Standard
High-Gloss Gun Metal
