LIGHT ENGINE
DLP® Type 3 Chip DMDs 0,95” 1080p DC4
Resolution 1920x1080 pixels
Brightness up to 3000 Ansi Lumens (adjustable)
Lens High quality, high resolution improved optics for higher contrast and better black level with motorized zoom and focus adj.
Special features Puremotion 3D technology with triple flash, Puremotion 2D for fast action materials, Puremovie 2D
Lamp power consumption 280W dimmable to 230W
Lamp life expectancy 2000 hours typical in standard power mode; 3000 hours in ECO mode

INSTALLATION
Throw ratio standard lens 1.75-2.48:1 (type T2)
Throw ratio optional lenses
1.37-1.66:1 (typ. T1)
2.6-3.9:1 (typ. T3)
Optical shift manual up half picture (+50%) and Digital keystone adjustment (for 2D and 3D 1080p24 modes)
Picture size (inches diagonal) 50-300
Aspect ratio 4:3, 16:9 Anamorphic, LetterBox, Panoramic, Pixel to Pixel + 3 custom-user adjustments

ELECTRONICS
Horizontal & vertical scan freq. 15-80kHz/24-144Hz
SDTV PAL (B,G,H,I,M,N,60); SECAM; NTSC autom. selected
HDTV 480p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p
PC graphic standard VGA, SVGA, XGA, SXGA, UXGA, WUXGA 10 bit Full Channel Signal Board Video Processing

INPUTS/OUTPUTS
Digital
2 x HDMI-HDCP vers. 1.4a with InstaPort
Analog
1 x Graphic RGBVH (VGA-UXGA) (D-sub 15 pin)
1 x Component - Analog YPbPr/RGBs/RGBHV (RCA)
Control
3D Sync out
1 x RS232 (D-sub 9 pin)
1 x USB
Miscellaneous
3 x 12V 100mA output (via Jack)

GENERAL SPECIFICATIONS
Software control upgradable via RS232, serial interface or USB
Mains voltage range 100-240 +/-10% (48/62 Hz)
Projector Weight 11 Kg. or 24.3 lbs

ACCESSORIES
Supplied Installation and User Manual
AC power cords (2m - 6.6 ft)
Backlit remote control and batteries
Live Colors Calibration software 2.0
Premium Active Glasses (4 pcs.)
IR Emitter
Optional
Projector ceiling bracket
Anamorphic lens systems (fixed or motorized)
Additional active glasses
