D250LS

The D250LS is a 2-channel amplifier with automatic switching and a space-saving low-profile design.

Switches speakers between a local source and a distributed audio system
Four mounting options available with included hardware
Low-profile design permits use in areas most amplifiers won't fit
Channels are bridgeable to create one channel with substantial power output
Robust circuitry is designed for long-term stability

Belongs to the series: R-Series Amplifiers

View it in the official brand website

Shipping Dimensions 12.5" (W) x 5.0" (H) x 11.5" (D)
(31.8 x 12.7 x 29.2 cm)
Shipping Weight 7.3 lbs (3.3 kg)
Amplifier Channels 2
Channel Separation >60dB @ 1 kHz
Frequency Response 20 Hz to 20 kHz +/- 0.4 dB
Fuse Rating T3.15AL/250V
Input Impedance 47 kilohms Line Input
Input Sensitivity 70 mV for 1 watt at 8 ohms
550 mV for 50 watts at 8 ohms
Power Consumption (Standby) <0.5 watts
Power Output Continuous Stereo:
50 watts per channel at 8 ohms (<0.3% THD+N) @ 1kHz
75 watts per channel at 4 ohms
150 watts at 8 ohms, 2 channels bridged
Power Requirement(s) North American: 120 VAC 60 Hz 2.5A
European: 230 VAC 50 Hz 2.5A
IEC 320 type connector with 3 terminal detachable power cord
Signal to Noise Ratio >112 dB A-weighted
Switching Delay 5 seconds to 5 minutes
Total Harmonic Distortion <0.3% THD+N from 20 Hz to 20 kHz for 50W into 8 ohms
<0.05% from 20Hz to 20kHz for 1W into 8 ohms
Trigger Input(s) 12 VDC 10 kilohms
Trigger Output(s) 12 VDC 100 mA max
Voltage Gain 32 dB
Zone Outputs 1
