Robust circuitry designed for stability under demanding loads.
Installs with either attached feet or included rack ears.
Shipping Dimensions:24.0" (W) x 13.0" (H) x 24.0" (D) (61.0 x 33.0 x 61.0 cm).
Shipping Weight:48.9 lbs (22.2 kg).
Amplifier Channels:12.
Frequency Response:20 Hz to 20 kHz +/-0.3 dB.
Fuse Rating:US/Canada: T15AL 250 V
Europe: T10AL 250 V
Input Impedance:47 kilohms.
Input Sensitivity:70 mV for 1 W at 8 ohms
500 mV for 50 W at 8 ohms
Power Output:Single Zone Maximum:
(0.1% THD+N; f=1 kHz)
50 W per channel, 2 channels at 8 ohms
80 W per channel, 2 channels at 4 ohms
140 W at 8 ohms, 2 channels bridged

All Zones Continuous:
35 W per channel, 12 channels at 8 ohms
50 W per channel, 12 channels at 4 ohms
100 W at 8 ohms, each zone bridged
Power Requirement(s):US/Canada: 120 VAC 60 Hz 7 A
Europe: 230 VAC 50 Hz 4 A
Signal to Noise Ratio:>100 dB.
Switching Delay:0.5 to 4.5 minutes.
Total Harmonic Distortion:<0.05% THD+N from 20 Hz to 20 kHz.
Trigger Input(s):12 VDC 10 kilohms.
Trigger Output(s):12 VDC 100 mA.
Voltage Gain:32 dB.
Zone Outputs:6.
