Projection system
Technology DLP® 1-Chip DarkChip3™ DMD
DMD Panel Resolution 1920x1080 pixel (Full HD)
Aspect Ratio (W:H) 16:9 (4:3 available via electronic vignetting)
Brightness 1000 lumen (ANSI - at 8800°K) 150W HBD VERSION
Uniformity >90% ANSI measurement
Contrast Ratio >4500:1 "full on/full off"
Number of colors 1,073,741,824 colors
Colour Temperature 6.500°K-5 selectable, 3500°K reachable
Lamp type dimmable 150W/132W High Pressure
Average life 132W 10.000 hrs* (50% survival @50% integral lm maintenance)
150W 6.000 hrs* (50% survival @50% integral lm maintenance)
Picture size 50" to 100" inches
Projection lens telecentric; multicoating elements f#=3, Manual focus adjustment
Throw ratio 0.673:1 (at 50"); 0.680:1 (at 67"); 0.687:1(at 100")

Electronics
Horizontal Frequency 15KHz-110 KHz
Vertical Frequency 48Hz-120 Hz
Analog Bandwidth 3dB at 170MHz for video and graphic signals with fH>15kHz;
2dB at 8MHz for video signals with fH=15kHz
Graphic Standards from 640x480 (VGA) to 1600x1200 (UXGA)
Video Standard Automatic recognition and decoding PAL, NTSC, SECAM. Internal motion-adaptive deinterlacing
Internal Magnification from 0,75x to 16x
HD video standard ATSC HDTV (480p, 720p, 1080i, 1080p, 1035i)

Connections
INPUTS 1 x RGB+HV (or YPrPb) on 75 ohm BNC connectors
1 x RGB+HV (or YPrPb or RGB+S) on HD15 connectors
1 x CVBS (in/out) on 75 ohm BNC connectors
1 x S-VIDEO (in/out) on miniDIN4 connectors
ATSC HDTV is also supported on BNC or HD15 or DVI connectors
DVI INPUT/OUTPUT Analog RGBHV (or YPrPb) + Digital RGB
DigitalDVI1.0 specification single link up to 165 MHz
Analog RGBHV (or YPrPd)+ Digital RBG;
Active loop through for the digital link
Control Interface serial Interface RS232C or RS485 on DB9 in/out
Connectors or USB (on request) for control from a remote
PC- IR, remote control handset (on request)

Electrical Data
Main Power Supply 100-240V~ 60/50Hz Automatic recognition with Power factor correction
Power Consumption 250 W max (215 Kcal/h or 853 BTU/h)
Max Current Absorption 2.5 Arms @100VAC -1.0 Arms @240VAC (HBD 150W versions)
Max Inrush Current 40 A
Fuse T 3.15A H 5x20mm

Mechanical Data
Package dimensions 590x450x400 mm (WxHxD)
Engine dimensions 486x280x278 mm (WxHxD)
Gross Weight 19,5 Kg with all accessories
Installation position Standard: horizontal (based on the rubber feet);
Vertical (with a vertical projection lens axis)
Allowable: tilt around the lamp axis: from 0° to 360°

Environmental Data
Exhaust Air 48°C (@ 35°C environment)
Ambient Temperature
Operating from 0° to +35°C
Storage and Transportation from -10°C to +55°
Humidity from 10% HR to 90% (without condensation)
Max Altitude
Operating 4.000 m
Transportation 11.000 m

Safety and regulatory data
Drop Test in compliance with UNI-EN 22247 and 22248
Safety in compliance with EN 60950, UL60950
EMC emission in compliance with EN 55022 Class A
EMC immunity in compliance with EN 55024
