Line output connection for external amplifier or subwoofer.
Dual-color keypad illumination.
Shipping Dimensions:3.0" (W) x 4.5" (H) x 2.5" (D) (7.6 x 11.4 x 6.4 cm)
Shipping Weight:0.4 lbs(0.2 kg).
Audio Input Impedance:30 Kohms.
CAT-5e Connection:RJ-45 jack, T568A standard.
Controls:Power on / off
Source select (with multisource hub)
Volume up / down.
Display:5-character LCD panel with source and volume indication.
Indicators:System status:LED (green)
IR confirmation:LED (red).
IR Control:Built-in IR receiver with pass-through.
Keypad Backlight:User-selectable green or amber.
Line Output:Variable line level, stereo.
Max Cable Length:150 feet (46 m).
Power Requirement(s):24 VDC 1050 mA peak.
Speaker Connection(s):Screw terminal connectors.
Accept up to 16 AWG (1.5 mm) wire.
Speaker Impedance:8 ohms per channel.
