BP10D

The PlateMate Modular 5-Way Binding Post Plate is a Decora® style plate with two (BP10D) pair (black and red) of 5-way binding post connectors for use in audio installations.
The 5-way binding posts have gold plating to resist corrosion and can accept bare or tinned wire up to 12 gauge in thickness; pins, spade lugs, and single or double banana plugs.

Belongs to the series: Platemate

Pin connector - Loosen the hex head, insert the pin into the side hole on the binding post, then tighten the hex head.
Spade connector - Loosen the hex head. Insert the spade so that it hugs the binding post, then tighten the hex head.
Banana plug connector - Make sure the hex head is tight on the binding post. Insert the banana plug as far as it will go into the top hole of the binding post.
Bare or tinned wire - Strip the speaker wires, exposing approximately 1/2 inch (14mm) of wire. Individually twist each conductor to keep the strands of wire bundled
together. Loosen hex head, insert wire into the side hole of the binding post, then tighten the hex head.
