Shipping Dimensions      13.0" (W) x 11.7" (H) x 12.4" (D)
(33.0 x 29.8 x 31.5 cm)
Shipping Weight              14.7 lbs (6.7 kg)
Cutout Dimensions      8.375" dia. (21.3 cm)
Dispersion Adjustment      Twist & Tilt, 0° or 15° angle
Finish                      White (paintable)
Frequency Adjustment      Treble & Bass switches (+3/0/-3dB)
Frequency Response      42Hz-22kHz -6dB/ +/-3dB
Impedance              4/5/6 ohms
Mounting Depth              4.5" (11.4 cm) @ 15 degree tilt
Overall Dimensions      9.75" dia. (24.8 cm)
Recommended Power      10-150 watts RMS
Rough-in Bracket      SB-C67 (not included)
Sensitivity              90dB SPL 2.83V @ 1m
Speaker Connection(s)      Gold-plated binding posts
Tweeter                      Pivoting 1.0" (25 mm) titanium
Type                      2-way in-ceiling
Woofer                      7" (17.8 cm) kevlar
