HF unit
25mm neodymium tweeter with high dispersion diaphragm. Ferro fluid cooled and damped. Magnetically shielded.

MF unit
180mm mid range driver with 32mm coil, polymer chassis, high power, long-throw magnet system and lightweight alloy cone. Magnetically shielded.

LF unit
180mm bass driver with 32mm coil, polymer chassis, high-power, long-throw magnet system and lightweight alloy cone. Magnetically shielded.

Power Handling  200W max

Frequency response +/-6db 37Hz to 23kHz

Sensitivity 90.5 db/W

Impedance 8 ohms

Cabinet Real wood veneered. 15mm MDF wrap with 30mm MDF front baffle. Full circumferential brace. High power, low turbulence bass reflex ports.

Terminals Gold-plated 2-way binding posts.

Weight
(excl. packaging) 18kg

Dimensions
Width 210 mm
Height 920 mm
Depth 395 mm
