Interactive Presenter Features
Interactive function permits real-time annotation of projected image.
Pen & pointer function as both writing instruments & computer mouse.
Included software for advanced functionality, including screen capture.
Ultrawide Projector Features
Extremely Short Throw Lens: as close as a 1 : 1 Throw-to-Width Ratio
2600 ANSI Lumens, 85% uniformity, and 500:1 contrast ratio.
Weighs less than 9 lbs! Compact, low-profile design!
3 panel LCD imaging delivers a rich, color saturated picture.
XGA resolution. UXGA ~ VGA compatible.
Smart data compression / expansion, and video scaling.
Two computer inputs, plus one computer monitor output.
Preset image offset. Vertical digital keystone correction.
Auto Ceiling adjustment. Auto Brightness adjustment.
Accepts Composite, S, and Component Video in all major standards.
Displays both 4:3 and 16:9 formats. Supports most HDTV resolutions.
Wireless remote control w/Laser. 4X digital zoom. Auto input search.
Closed caption decoding. Built-in LAN (RJ-45)

Image Characteristics
Brightness up to 2600 ANSI Lumens
Contrast Ratio - Full ON/OFF 500:1
Illumination Uniformity (corner to center) 85%
Imaging System 0.63” PolySilicon active matrix TFT Panels x 3
Scanning Frequency Auto: H Sync. 31-92kHz; V Sync. 48-120Hz
Screen Pixels 1024 x 768 in stripe configuration
Size of Color Palette 16.7 Million
Total Pixels 2,359,296 ((1024 x 768) x 3)

Image Control
Anti-Keystone Fixed Image Offset, Ratio (Top:Bottom) 5:1
Front Elevation Up to 8.5° Up
Image Orientation Normal, Reversed, Inverted
Vertical Anti-Keystone Digital: up to 30° up or down

Estimated Lamp Life Hours up to 3000 Hours of Use
Lamp 230 Watt NSH

Supplied Lens
Focal Length - Max. 0.87 in. (22.18 mm)
Focal Length - Min. 0.72 in. (18.53 mm)
Image Diagonal - Max. 300 in. (762 cm)
Image Diagonal - Min. 40 in. (101.6 cm)
Lens Speed f:1.65~1.93
Lens Type Manual Zoom & Focus
Throw Distance - Max. 20.07 ft. (6.12 m.)
Throw Distance - Min. 2.52 ft. (0.77 m.)
Throw:Width ratio 0.97~1.19:1
Zoom Ratio - Max:Min: 1.2:1

Computer Specifications
Computer Compatiblity UXGA, SXGA+, SXGA, XGA, SVGA, VGA
Computer Formats Supported 1600 x 1200, through 640x480
Computer Higher Resolution Displayed panned or Smart Compressed
Computer Lower Resolution Displayed normal or Smart Expanded
Computer Native Resolution 1024 x 768
Pixel Clock 162 MHz

Video Specifications
Video: Color Systems NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
Video Formats 4:3 & 16:9
Video: HD Compatibility 480i/p, 575i/p, 720p, 1035i, 1080i
Video: Image Sizing Video Scaling Technology

Physical Specifications
Cabinet Height 4.4 in. (111.9 mm)
Cabinet Width 12.79 in. (325mm)
Cabinet Depth 10.51 in. (267 mm)
Packaged Height 9.9 in (251 mm)
Packaged Width 17.7 in (450 mm)
Packaged Depth 13.8 in (350 mm)
Packaged Weight 13.7 lb (6.2 kg)
Weight 8.53 lb (3.87kg)

Audio Specifications
Amplifier 8 Watts (Mono)
Speakers (Built-in) 1.6 x 1.2 in. (4x3 cm) x 1(Ellipse)

Electrical Specifications
Power Requirements 100 ~ 240 V AC, 50/60 Hz
Power Consumption Up to 315 W

Generated Heat up to 853 BTU (215 KC)
Operating Noise - dBA as low as 40 dBA
Operating Temperature - Max. 95°F (35°C)
Operating Temperature - Min. 41°F (5°C)

Eco-Mode Specifications
Estimated Lamp Life Hours (ECO Mode) up to 3000 hours

UPC 4571194673388

User Maintenance
maintenance Replace Air Filter, Replace Lamp
