LIGHT ENGINE
DLP™ Type Proprietary sealed optical Engine based on 1 HD2 DMD™ Chip.
Resolution 1280x720 pixels
Lens High quality, high resolution optics with both motorised zoom and focus adjustments
Throw ratio(16:9 mode) 1.8 - 2.4:1
Throw ratio (4:3 mode) 2.4 - 3.0:1
Lamp power consumption & life time 120W, 6000 hours*

INSTALLATION
Optical keystone adjustment +/-8°
Digital keystone adjustment +/-19° vertical, +/-12° horizontal
Picture size 50-300 inches diagonal.
Aspect ratio 4:3, 16:9, anamorphic, letter box plus 3 custom-user adjustments, panoramic and pixel to pixel

ELECTRONICS
Horiz. Scan freq. 15-80KHz (max horizontal freq. corresponding to UXGA, 60Hz)
Vert. Scan freq. 48-100Hz
Video standard & graphic resolutions PAL B,G,H,I,M,N,60, SECAM, NTSC 3.58 &4.43 automatically selected; HDTV: ATSC (480p, 1080i); VGA, SVGA, XGA, SXGA, UXGA
DCDi™ by Faroudja built-in
Contrast Ratio (full On / full Off) > 2000:1
Colour Temperature 3 preset colour temperatures selectable by remote control + 1 user adjustment

INPUTS/OUTPUTS
Analog
1 x Composite video via RCA connectors
1 x S –VHS via mini Din 4 pin
1 x RGBHV via Dsub 15 (PC input)
1 x RGBS/YCrCbS via 4xRCA connectors
1 x RS232 on Dsub 9 pins connector

General Specifications
Control Software can be upgraded via RS232 serial interface
Power Consumption 170 W max
Mains voltage range 120 - 240 Vac, -/- 10%
Mains frequency range 48/62 Hz
Cabinet dimensions (W x H x D) 350 x 167 x 318mm (13,8” x 6,6” x 12,5”)
Weight 5.0 Kg. (11 lbs)


CERTIFICATIONS
Safety In compliance with EN 60950/UL 1950
Emission In compliance with EN 55022 class B/150KHz - 30MHz
Recyclable packaging

ACCESSORIES
Supplied AC power cords (EU,UK, and USA) length 3m
User standard remote control with batteries
Installation and user manual
